Online 1:1 Transformer based UPS
EnerbyteTech’s Single‑Phase Transformer‑Based Online Double Conversion UPS delivers exceptional power protection with a reliable pure sine wave output and stable double conversion design that minimizes distortion and eliminates fluctuations. Equipped with a built‑in isolation transformer, it provides strong anti‑interference capability, while its input voltage range of 165–275 Vac reduces unnecessary battery switching even in harsh environments. Advanced charging technology extends battery life and supports cold starts directly from the battery during outages. Comprehensive safeguards against overload, short‑circuit, and temperature ensure system stability, while RS232 communication and optional SNMP adapter enable easy monitoring and remote management, making it an ideal solution for sensitive loads.
Choose your Model
Technical Specification
GP118 Series 6KVA UPS Single Phase Online Double Conversion UPS with integrated Output Transformer, Additional Input Harmonic Filtering, Semi Industrial Grade
Capacity (VA/Watts): 6000VA/4800W
| Input | |
|---|---|
| Nominal voltage | 220 / 230 Vac |
| Operating voltage range | 165~275 Vac |
| Operating frequency range | 50/60 Hz(±5%) |
| Power Factor | >0.97 (with filter) |
| Max. input current (A) | 31 Amps |
| Output | |
|---|---|
| Output voltage | 220 Vac (±0.5%) / 230 Vac (±0.5%) |
| Output frequency | 50/60 Hz (±0.5%) |
| Crest factor | 3:1 (max) |
| Efficiency | >84% |
| Harmonic distortion (THD) | < 1.5% (linear load) |
| Environment | |
|---|---|
| Operating Temperature | 0 ~ 40 °C |
| Storage Temperature | -25 ~ 55 °C |
| Relative Humidity | 0 ~ 95% (non-condensing) |
| Altitude | < 1500m |
| Noise level | < 55 dB |
| System Features | |
|---|---|
| Transfer time | 0 ms (Line mode to Battery mode) |
| Overload | Load ≤125% : 1 min, ≤150% /200ms, to Bypass |
| Communication interface | RS232, SNMP (optional), Dry contact (optional) |
| Battery | |
|---|---|
| Battery Voltage | 192Vdc |
| Standard | |
|---|---|
| Safety | IEC/EN62040-1; lEC/EN62477-1 |
| EMC | lEC/EN62040-2; IEC61000-4-2; IEC61000-4-3; IEC61000-4-4; IEC61000-4-5; IEC61000-4-6; IEC61000-4-8 |
| Physical | |
|---|---|
| Weight | 108 Kg |
| Height | 720 mm |
| Width | 230 mm |
| Length | 580 mm |
Features
High Reliability Design:
- Double conversion on-line design provides pure sine wave output.
- Includes tracking frequency, phase-lock, voltage regulation, and low distortion.
- Eliminates power fluctuation interference, ensuring comprehensive protection for connected loads.
Strong Load Protection:
- Built-in isolation transformer with strong anti-interference capability.
- Delivers enhanced protection for sensitive equipment.
Wide Input Range:
- Supports a wide input voltage range of 165-275 Vac, minimizing battery usage in harsh environments.
- Accommodates a wide input frequency range for stable operation with various fuel generators.
Optimized High-Performance Battery:
- Advanced floating switching and charging technology maximizes battery activation.
- Reduces charging time and extends battery life.
Battery Cold Start Function:
- Can be started directly by the battery when utility power is unavailable, ensuring uninterrupted power during emergencies.
- Strong cold start capability allows operation even at full load.
Comprehensive and Reliable Protection:
- Self-diagnosis function before start-up to prevent potential risks.
- Multiple protection features including overload, short-circuit, over-temperature, battery under-voltage, and over-charge protection.
- Built-in static electronic bypass switch for continuous power supply in case of UPS failure.
- DC start function enables starting the UPS directly without AC power for emergency situations.
User-Friendly Network Management:
- RS232 communication capability with monitoring software for real-time parameter display.
- Optional external SNMP adapter for remote network management and real-time data communication through various network systems.
Online 1:1 Transformer less UPS
Online 3:3 Transformer based UPS
VRLA AGM
Technical Specification
GP118 Series 12KVA UPS Single Phase Online Double Conversion UPS with integrated Output Transformer, Additional Input Harmonic Filtering, Semi Industrial Grade
Capacity (VA/Watts): 12000VA/9600W
| Input | |
|---|---|
| Nominal voltage | 220 / 230 Vac |
| Operating voltage range | 165~275 Vac |
| Operating frequency range | 50/60 Hz(±5%) |
| Power Factor | >0.97 (with filter) |
| Max. input current (A) | 50 Amps |
| Output | |
|---|---|
| Output voltage | 220 Vac (±0.5%) / 230 Vac (±0.5%) |
| Output frequency | 50/60 Hz (±0.5%) |
| Crest factor | 3:1 (max) |
| Efficiency | >85% |
| Harmonic distortion (THD) | < 1.5% (linear load) |
| Environment | |
|---|---|
| Operating Temperature | 0 ~ 40 °C |
| Storage Temperature | -25 ~ 55 °C |
| Relative Humidity | 0 ~ 95% (non-condensing) |
| Altitude | < 1500m |
| Noise level | < 55 dB |
| System Features | |
|---|---|
| Transfer time | 0 ms (Line mode Battery mode) |
| Overload | Load ≤125% : 1 min, ≤150% /200ms, to Bypass |
| Communication interface | RS232, SNMP (optional), Dry contact (optional) |
| Battery | |
|---|---|
| Battery Voltage | 192Vdc |
| Standard | |
|---|---|
| Safety | IEC/EN62040-1; lEC/EN62477-1 |
| EMC | lEC/EN62040-2; IEC61000-4-2; IEC61000-4-3; IEC61000-4-4; IEC61000-4-5; IEC61000-4-6; IEC61000-4-8 |
| Physical | |
|---|---|
| Weight | 108 Kg |
| Height | 720 mm |
| Width | 230 mm |
| Length | 580 mm |
Features
High Reliability Design:
- Double conversion on-line design provides pure sine wave output.
- Includes tracking frequency, phase-lock, voltage regulation, and low distortion.
- Eliminates power fluctuation interference, ensuring comprehensive protection for connected loads.
Strong Load Protection:
- Built-in isolation transformer with strong anti-interference capability.
- Delivers enhanced protection for sensitive equipment.
Wide Input Range:
- Supports a wide input voltage range of 165-275 Vac, minimizing battery usage in harsh environments.
- Accommodates a wide input frequency range for stable operation with various fuel generators.
Optimized High-Performance Battery:
- Advanced floating switching and charging technology maximizes battery activation.
- Reduces charging time and extends battery life.
Battery Cold Start Function:
- Can be started directly by the battery when utility power is unavailable, ensuring uninterrupted power during emergencies.
- Strong cold start capability allows operation even at full load.
Comprehensive and Reliable Protection:
- Self-diagnosis function before start-up to prevent potential risks.
- Multiple protection features including overload, short-circuit, over-temperature, battery under-voltage, and over-charge protection.
- Built-in static electronic bypass switch for continuous power supply in case of UPS failure.
- DC start function enables starting the UPS directly without AC power for emergency situations.
User-Friendly Network Management:
- RS232 communication capability with monitoring software for real-time parameter display.
- Optional external SNMP adapter for remote network management and real-time data communication through various network systems.
